This it the Kit for the upgrade Chin Boards and Light Up ear to a Guy Manuel Helmet. Once assembled, this kit installs easily into your Guy Man Helmet. This is an upgrade kit, in order for it to work properly, it must be connected to a Guy Manuel kit.
Differences between Original (V1) and V2 kits:
-No need to solder a 16Mhz Crystal, it comes pre-soldered
-No need to solder the 22pf Capacitors, they are pre-soldered
-Mode select button, individual control of Ears and Sidebars.
Here is what the V1 Ears and chins look like when assembled:
Please note that there are No Returns!
1 x Left Chin PCB
1 x Right Chin PCB
1 x Right Ear PCB
1 x Left Ear PCB
1 x Ear light Filter
1 x Chin Light Filter
1 x Control Board (V2)
50 x 5mm Straw Hat White LEDs
2̶ ̶x̶ ̶1̶6̶M̶h̶z̶ ̶C̶r̶y̶s̶t̶a̶l̶s̶
3̶ ̶x̶ ̶1̶8̶p̶f̶/̶2̶2̶p̶F̶ ̶C̶a̶p̶a̶c̶i̶t̶o̶r̶s̶ ̶(̶1̶0̶,̶ ̶1̶6̶,̶ ̶2̶5̶,̶ ̶o̶r̶ ̶5̶0̶ ̶V̶o̶l̶t̶s̶)̶
4 x 10-22uF Capacitors (10, 16, 25 or 50 Volts) Electrolytics
4 x 0.1uF Capacitors (10, 16, 25 or 50 Volts) Ceramic
100 x 2x5x7mm White Rectangular LEDs
20 x 330 Ohm Resistors (1/4 or 1/8 Watt)
4 Feet 50 Conductor Flat Cable
5 x 47k Resistors (1/4 or 1/8 Watt)
3 x Max7219
2 x 5mm Green LEDs
2 x 5mm Red LEDs
4 x 6mm Push buttons
Soldering Iron (~30 Watts)
Double Sided (clear) tape
Do I have to purchase additional parts to complete this kit?
Yes, check the Parts Required list above.
Where can I purchase the Required parts?
Ebay is the best option.
Do I have to be able to write code to assemble this kit?
Nope, the kit comes with a pre-programmed chip.
What skills are required to complete the kit?
Being able to solder is a MUST! Everything else is more-or-less straightforward.
Does the kit come with a helmet?
Nope, the kit comes with only the electronics.
Does this kit come assembled?
Nope, you have to assemble it yourself.
How difficult is it to assemble?
On a scale of 1-to-10, around 4.
Is there a way I can buy the kit assembled?
Is there a way you could sell a kit with all the parts required to complete the kit?
Yep, right here.
Do you ship world-wide?
Yes, I do.
How long does International Shipping take?
Roughly 1-3 weeks.
I have some more questions!
Tweet them at me, I'll try my best to reply quickly.
